SV Series Spa Controls
SV Series Overview
3
Mains Power
Terminal Block
Heater Connection
Terminal Block
Earth Bonding
Terminal
Fuse 1
(Phase 3 Loads)
Fuse 2
(Phase 2 Loads)
Fuse 3
(Phase 1 Loads)
Heater Tube
AMP Power Outlets
(230-240V AC)
for spa accessories:
circ, o /uv, air blower
3
jet pumps, auxiliaries
Coupling
(tail & nut)
Coupling
(tail & nut)
Wall Mount
Bracket
Wall Mount Bracket
Heartbeat LED
Low Voltage Connections
(12V)
keypads, lights, in-pool sensor
digital/analog expand ports
Mains Power
Cable Entry
Points
Mounting Foot
Heater Cover Plate
(remove to access
heater connections)
DIP Switch Bank
