23
16. Om het slachtoffer te laten zakken, moet de
reddingswerker het touw vastnemen dat de GRIGRI
verlaat, en hiermee de neerlating regelen.
17. Met de andere hand ontgrendelt hij de zwarte handgreep
op de GRIGRI tot het touw met een regelbare snelheid
kan doorlopen. Op die manier gaat het slachtoffer
omlaag. (Zie opmerking)
OPMERKING: Om het reddingswerk uit te voeren,
moet de reddingwerker een harnas hebben met een
bevestigingspunt aan de voorzijde voor de GRIGRI. Als
het ankerpunt voor de GOTCHA™ dusdanig is dat het
slachtoffer moet worden neergelaten, moet het touw
in de kit vier keer zo lang zijn als de afstand tussen de
verankering en de veilige plek.
Verankering op voetniveau.
1. Ga naar het ankerpunt van het slachtoffer.
2. Bevestig de ankerstrop op een geschikt verankeringspunt
boven het slachtoffer.
3. De reddingswerker gebruikt zijn benen om het touw in te
trekken.
De enkelvoudige katrol wordt op de ankerstrop geklikt.
4. Regel de staak af op de gewenste lengte.
5. Bevestig de rode clip op het uiteinde van de staak en klik de
dubbele katrol in de singel.
6. Regel de touwen tussen de katrollen af op dezelfde lengte
als de staak.
7. Zet de rode clip open.
8. Gebruik de staak om de rode clip te bevestigen op het
harnas van het slachtoffer.
9. Haal de staak uit de rode clip.
10. Bevestig de GRIGRI op het harnas van de reddingswerker.
11. Trek het overtollige touw door de GRIGRI om het systeem op
te spannen en hurk neer.
12. De reddingswerker gaat nu staan, waardoor het slachtoffer
omhoog gaat.
13. De reddingswerker houdt het touw onder de GRIGRI met
één hand vast, dicht bij de bevestigingsstrop. Met de
andere hand haalt hij het overtollige touw in terwijl hij
neerhurkt.
14. Als het gewicht van het slachtoffer overgebracht is naar de
GOTCHA™, kan zijn veiligheidstouw worden losgekoppeld.
INSTALLATION & USE : INSTRUCTIONS
Anchor more than 1.5m above foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuers weight is used to assist in the operation.
The double pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
single pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same length
as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system.
12. The rescuer now sits down, thus raising the casualty.
13. With one hand, the rescuer holds the rope above the
GRIGRI, close to the attachment sling. With the othe
hand they take in the slack rope as they stand up.
14. Once the casualty’s weight has been transferred to the
GOTCHA™, then their lanyard can be disconnected.
15. The casualty can now be raised to a point of safety, o
lowered as follows.
16. To lower the casualty the rescuer must take hold of the
rope that exits the GRIGRI, and this is used to control
the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
16-17
5
7
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
If the anchor point for the GOTCHA™ is such that the casualty must be lowered, then the rope length in the kit must
be four times the distance from the anchorage to the point of safety.
11-13
8
HIGH
ANCHOR
Blue Pulle
INSTALLATION & USE : INSTRUCTIONS
Anchor more than 1.5m above foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuers weight is used to assist in the operation.
The double pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
single pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same length
as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system.
12. The rescuer now sits down, thus raising the casualty.
13. With one hand, the rescuer holds the rope above the
GRIGRI, close to the attachment sling. With the othe
hand they take in the slack rope as they stand up.
14. Once the casualty’s weight has been transferred to the
GOTCHA™, then their lanyard can be disconnected.
15. The casualty can now be raised to a point of safety, o
lowered as follows.
16. To lower the casualty the rescuer must take hold of the
rope that exits the GRIGRI, and this is used to control
the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
16-17
5
7
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
If the anchor point for the GOTCHA™ is such that the casualty must be lowered, then the rope length in the kit must
be four times the distance from the anchorage to the point of safety.
