27
16. For å senke den skadde må redningsarbeideren ta tak
i tauet som går ut av GRIGRIen, og dette benyttes til å
kontrollere nedfiringen.
17. Med den andre hånden løsnes det sorte håndtaket på
GRIGRIen til tauet mates i kontrollerbar hastighet.
Dermed senkes den skadde. (Se merknad under)
MERK: For å utføre redningsoperasjonen må
redningsarbeideren ha en sele med fremre festepunkt
til plassering av GRIGRIen. Dersom ankerpunktet til
GOTCHA™ er slik plassert at den skadde må senkes,
må settets taulengde være fire ganger avstanden fra
ankerpunktet til det sikre stedet.
Ankerpunkt ved fotnivå.
1. Oppnå tilgang til den skaddesankerpunkt.
2. Fest ankerslyngen til et passendeankerpunkt over den
skadde.
3. Redningsarbeideren brukerderes ben til å dra inn tauet.
Den enkletrinsen spennes fast på ankerslyngen.
4. Juster staken til ønsket lengde.
5. Fest den røde klemmen til enden av staken,og den doble
trinsen spennes fast i båndet.
6. Juster tauene mellom trinsene, slik at de fårsamme
lengde som staken.
7. La den røde klemmen være åpen.
8. Benytt staken til å feste den røde klemmentil den skaddes
seletøyfeste.
9. Fjern staken fra den røde klemmen.
10. Fest GRIGRIen til redningsarbeiderensseletøy.
11. Gi slakk i tauet ved hjelp av GRIGRIen for åsette systemet
i spenning, og sett deg påhuk.
12. Redningsarbeideren reiser seg så, og heverpå denne
måten den skadde.
13. Redningsarbeideren holder tauet underGRIGRIen nær
festeslyngen med én hånd.Med den andre hånden tas
tauet med slakkinn når redningsarbeideren setter seg
påhuk.
14. Når den skaddes vekt er overført tilGOTCHA™, kan
taljereipet kobles fra.
15. Den skadde kan nå senkes på følgendemåte.
16. For å senke den skadde måredningsarbeideren ta
INSTALLATION & USE : INSTRUCTIONS
Anchor more than 1.5m above foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuers weight is used to assist in the operation.
The double pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
single pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same length
as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system.
12. The rescuer now sits down, thus raising the casualty.
13. With one hand, the rescuer holds the rope above the
GRIGRI, close to the attachment sling. With the othe
hand they take in the slack rope as they stand up.
14. Once the casualty’s weight has been transferred to the
GOTCHA™, then their lanyard can be disconnected.
15. The casualty can now be raised to a point of safety, o
lowered as follows.
16. To lower the casualty the rescuer must take hold of the
rope that exits the GRIGRI, and this is used to control
the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
16-17
5
7
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
If the anchor point for the GOTCHA™ is such that the casualty must be lowered, then the rope length in the kit must
be four times the distance from the anchorage to the point of safety.
11-13
8
HIGH
ANCHOR
Blue Pulle
INSTALLATION & USE : INSTRUCTIONS
Anchor more than 1.5m above foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuers weight is used to assist in the operation.
The double pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
single pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same length
as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system.
12. The rescuer now sits down, thus raising the casualty.
13. With one hand, the rescuer holds the rope above the
GRIGRI, close to the attachment sling. With the othe
hand they take in the slack rope as they stand up.
14. Once the casualty’s weight has been transferred to the
GOTCHA™, then their lanyard can be disconnected.
15. The casualty can now be raised to a point of safety, o
lowered as follows.
16. To lower the casualty the rescuer must take hold of the
rope that exits the GRIGRI, and this is used to control
the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
16-17
5
7
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
If the anchor point for the GOTCHA™ is such that the casualty must be lowered, then the rope length in the kit must
be four times the distance from the anchorage to the point of safety.
11-13
8
HIGH
ANCHOR
Blue Pulle
