28
Anchorage at foot level.
1. Access casualty’s anchorage point.
2. Attach the anchor sling to a suitable anchor point
above the casualty.
3. The rescuer will use their legs to help pull in the rope.
The single pulley is clipped to the anchor sling.
4. Adjust pole to the required length.
5. Attach the red clip to the end of the pole, and clip the
double pulley into the webbing.
6. Adjust ropes in-between the pulleys to the same
length as the pole.
7. Set the red clip to open.
8. Using the pole, attach the red clip to the casualty’s
harness attachment.
9. Remove the pole from the red clip.
10. Attach the GRIGRI to the rescuers harness.
11. Pull the slack rope through the GRIGRI to tension the
system, and squat down.
12. The rescuer now stands up, thus raising the casualty.
13. With one hand, the rescuer holds the rope below the
GRIGRI, close to the attachment sling. With the
other hand they take in the slack rope as they squat
down.
14. Once the casualty’s weight has been transferred to
the GOTCHA™ then their lanyard can be
disconnected.
15. The casualty can now be lowered as follows.
16. To lower the casualty the rescuer must take hold o
the rope that exits the GRIGRI, and this is used to
control the descent.
17. With the other hand releases the black handle on the
GRIGRI until the rope can be fed at a controllable
speed. This thus lowers the casualty.(Please see
note)
INSTALLATION & USE : INSTRUCTIONS
LOW
ANCHOR
Green Pulley to Anchor Sling
5
7
11-13
8
17
NOTE: In order to carry out a rescue the rescuer requires a harness with a front point of attachment for locating the GRIGRI.
