SPAUN SMS 5607+ NF - Technical Specifications Overview

5
08.22
Technical Data
Modell
Art. Nr.
SMS 5607+ NF
815014
SMS 5807+ NF
842462
SMS 51207+ NF
842463
SMS 51607+ NF
842464
Subscriber outputs 6 8 12 16
Inputs SAT / terrestiral
5
4 / 1
Tap loss Terrestrial 5 … 862 MHz
19 dB ± 1 dB 19 dB ± 1 dB 23 dB ± 1 dB 23 dB ± 1 dB
Tap attenuation SAT - ZF 950 … 2200 MHz
4 … 1 dB ± 1 dB
Output level max. 950 … 2200 MHz 35 dB IMA
3
/ EN 60728 - 3
typ. 102 dBμV
SAT input level max. 90 dBμV 90 dBμV 92 dBμV 92 dBμV
Isolation Receiver / receiver Terrestrial / SAT
typ. 30 dB
Mains supply U~ 90 - 240 V / 47 - 63 Hz Input power Standby
typ. 0,1 W
LNB supply current max. 400 mA Current consumption from each receiver
38 mA
Power consumption incl. ECO LNB load with 100 mA
typ. 2,4 W
Ambient temperature - 20 … + 55 ° C Dimensions (mm) 208 x 136 x 43 208 x 136 x 43 290 x 136 x 43 290 x 136 x 43
Subject to technical improvements, changes in design and errors.
