Technical Data
4
VM, VMC, VMN series in-line pumps booster pumps are designed for a wide range of applications in various industries
for water treatment, water boosting, water supply, cooling, cleaning, etc.
Applications
Definition of Model
Technical data
Temperatures
Ambient temperature: 0°C to +40°C
Liquid temperature: -15°C to +120°C
If ambient temperatures are above +40 degrees °C, or if the pump is located at elevations more than 1,000
meters above sea level, the motor’s output must be decreased to compensate for less effective cooling, and may have to be
replaced with a stronger motor.
Electrical Data
See the motor nameplate.
Make sure that the supply voltages, phase and frequencies correspond to the motor specifications.
Number of starts per hour
Motors up to and including 4 kW: Maximum 100 times per hour.
Motors of 5.5 kW and up: Maximum 40 times per hour.
If you use another brand of motor then check the manufacturer’s instructions for the maximum frequency
of starts.
Identification Code
VM - 10 - 5 - SQQE
Code for shaft seal
Number of stages
Nominal flow ᇿm3/hሀ
Type Ranges
VM - 10 - 5 - SQQE
Code for shaft seal
Number of stages
Nominal flow (m
3
/h)
Type Ranges
Handling
Read these instructions carefully before beginning installation. Lift and handle these pumps carefully.
VM, VMC, VMN series are vertical multi-stage non-self priming pumps coupled with standard electric motors.
This manual applies to standard version pumps and for standard applications.
Contact your supplier or the factory for information about special pump versions and applications.
Pumped liquids
The pumps are designed for use with clean, viscous and non-explosive liquids that do not contain abrasive matter.
These pumps are not designed to be used with abrasive, solid containing, explosive and corrosive liquids.
For special application, please contact your supplier or the factory.
