Page 2 Eazy6 Owner’s Manual
Page 2 WeatherCraft
™
WS900 Series Owner’s Manual
MODE SWITCH SETTINGS
In order to obtain optimum sound coverage for your application, use the Mode Switches to select the channel(s) you want to
play out of each side of the cabinet — Left, Right, or Left + Right (See Figure 4).
IMPORTANT NOTE: Each Mode Switch affects the output of the speaker directly in front of it. (See Diagram 5)
MOUNTING
Placement on a Wall
When placing your speakers on a wall, optimal sound will be achieved if they are mounted at ear level or slightly higher. The usual
listening area should be no closer to the speakers than the distance between the speakers themselves.
Placement Under Eaves and Outdoors
When mounting your speakers outdoors, the eaves of the roof provide an ideal location. They reduce the exposure of constant
direct sunlight, salt spray, and precipitation. If installing speakers on a boat, the wheelhouse provides the best location for the
same reasons. Following these suggestions will help to ensure that your speakers will last a lifetime.
Figure 4: Rear Panel
Figure 5: Mode Switch Orientation
Selects Right
Channel Only
Selects Both
Left + Right Channels
Speaker Wire Terminals
Selects Left
Channel Only
Left Mode Switch
Controls Left Speaker
Right Mode Switch
Controls Right Speaker
Top View of
WS950/WS940
