Speakman Sentinel Mark II User Manual

CPV-PB-DV-PXE ROUGH-IN DIAGRAM
SPEAKMAN
®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4’-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION
ONLY)
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
A
A
1/2" F1960
COLD EXPANSION
PEX CONNECTION
1/2" F1960
COLD EXPANSION
PEX CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTIONS
1/2" NPT MALE
1/2" SWEAT
CONNECTIONS
5-1/2" (140MM) DIA.
HOLE FOR
VALVE ACCESS
3-1/8" MIN
[80mm]
4-1/8" MAX
[105mm]
(ADJUSTMENT)
5
1
16
"
129mm
4
15
16
"
125mm
7"
178mm
2"
50mm
5
1
16
"
129mm
2
15
16
"
75mm
2
13
16
"
72mm
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI
A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
ASSE1016/ASME A112.1016/CSA B125.16
Hot/Cold Inlets: ½” F1960 Cold
Expansion PEX
Shower Outlet: ½” Female Copper Sweat
½” NPT Male
Tub Outlet: ½” Female Copper Sweat
½” NPT Male
(Cap included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 1.75 gpm (6.6 L/min)
or higher flow rate
4" [102mm]
TO TOP OF
TUB LEDGE
CPV-PB-PXE ROUGH-IN DIAGRAM
SPEAKMAN
®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4’-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION
ONLY)
4" [102mm]
TO TOP OF
TUB LEDGE
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
A
A
1/2" F1960
COLD EXPANSION
PEX CONNECTION
1/2" F1960
COLD EXPANSION
PEX CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTIONS
1/2" NPT MALE
1/2" SWEAT
CONNECTIONS
5-1/2" (140MM) DIA.
HOLE FOR
VALVE ACCESS
3-1/8" MIN
[80mm]
4-1/8" MAX
[105mm]
(ADJUSTMENT)
5
1
16
"
129mm
3
5
16
"
84mm
7"
178mm
5
1
16
"
129mm
2
15
16
"
75mm
2
13
16
"
72mm
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
FOR ADA MOUNTING LOCATIONS, CONSULT ADAAG, ANSI
A117.1, AND STATE REGULATIONS.
NOTES:
COMPLIANCE:
CONNECTIONS:
ASME A112.18.1/CSA B125.1
ASSE1016/ASME A112.1016/CSA B125.16
Hot/Cold Inlets: ½” F1960 Cold
Expansion PEX
Shower Outlet: ½” Female Copper Sweat
½” NPT Male
Tub Outlet: ½” Female Copper Sweat
½” NPT Male
(Cap included for Shower Only Connections)
Contractor to supply necessary inlet
connections.
NOTES:
This valve is designed to be used in conjunction
with a shower-head rated at 1.75 gpm (6.6 L/min)
or higher flow rate

Speakman Sentinel Mark II Specifications

General

Brand	Speakman
Model	Sentinel Mark II
Category	Control Unit
Language	English
