control if it comes up against objects which it
cannot cut through. This may result in
Serious injury. Keep onlookers and animals at
least 15 m away from where you are working. If
the machine strikes a foreign body, stop the
engine immediately and bring the blade to a
standstill. Check the blade for signs of damage.
Always replace the blade if it is bent or damaged.
3. THE BLADE WILL THROW UP OBJECTS AT
HIGH SPEED: This may cause injuries to eyes,
face and legs. Always wear eye, face and leg
protection. Remove all objects from the working
area before using the blade. Keep other people
and animals at least 15 m away from the
machine in all directions.
4. Check your machine and other equipment
carefully for signs of damage. Do not use the
machine unless all the blade mountings have
been installed correctly.
5. THE BLADE WILL SLOW DOWN AND STOP IF
YOU RELEASE THE THROTTLE VALVE.
While it is slowing down, the blade can still cause
injury to you or onlookers. Before you carry out
any work on the blade, switch off the engine and
make sure that the blade has stopped.
6. DANGER ZONE WITH A DIAMETER OF 15
METERS. Onlookers may suffer injuries. Keep
onlookers and animals at least 15 m away from
where you are working.
2. Machine layout and items
supplied (Fig. A – C)
A/1, B/1 Cutting head
A/2 Guard hood for blade
A/3, B/3 Guard hood for cutting line
A/4 Blade
A/5 Handle
A/6 Engine switch “ON/OFF”
A/7 Throttle lever “release”
A/8 Throttle lever
A/9 Throttle lever “lock”
A/10 Choke lever
A/11 Starter cable
A/12 Spark plug cover
A/13 Air filter housing cover
A/14 Petrol tank
A/15 Housing for engine cooler
A/16 Fuel pump “primer”
A/17 Long handle with drive shaft
B/18 Carrying strap
C/19 Oil/petrol mixing bottle
C/20 Spark plug wrench
C/21 Bolt for spark wrench
C/22 Open-ended spanner (8 mm / 10 mm)
C/23 Allen key (size 4)
C/24 Allen key (size 5)
C/25 2-stroke oil
Safety devices
When working with the blade the metal guard hood
must be installed and when working with the cutting
spool the plastic guard hood must also be installed to
prevent objects being thrown out by the machine. The
integrated blade in the plastic guard hood
automatically cuts the line to the optimum length.
3. Technical data
Engine type:
2-stroke engine, air-cooled, chrome cylinder
Engine output (max.): 0.8 kW / 1.1 bhp
Displacement: 30 cc
Idle speed of engine: 2800 +/- 200 rpm
Max. engine speed: 9000 rpm
Max. twin line speed: 6750 rpm
Ignition: Electronic
Drive: Centrifugal clutch
Weight (with empty tank): 7 kg
Long handle length: 149.5 cm
Cutting diameter: 41 cm
Cutting blade diameter: 23 cm
Cutting line length: 8 m
Cutting line diameter: 2.0 mm
Tank capacity: 0,8 l
Spark plug: CHAMPION RCJ6Y
Vibration a
hw
7,26 m/s²
Sound pressure level, L
pA
100 dB
Sound power level, L
WA
108 dB
Sound and vibration were measured in accordance
with DIN EN 11806.
4. Intended use
The machine is designed for cutting lawns and
grassed areas. The operating instructions as supplied
by the manufacturer must be kept and referred to in
order to ensure that the machine is properly used and
maintained. Any use which is not expressly permitted
in the manual may result in damage to the machine
and place the user in serious danger. Be sure to
observe the restrictions in the safety instructions.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes.
GB
12
