B = Blue Loctite required
Part #
1.a
1.b
1.c
1.d
1.e
1.f
1.g
1.h
Qty.
2
4
4
4
2
6
2
6
Part Description
BB Pivot Bearing
Dropout Pivot Bearing
Shock Link @ Frame Pivot Bearing
Shock Link @ Seatstay Pivot Bearing
BB Pivot Spacer
Dropout Pivot Spacer
Shock Link @ Frame Pivot Spacer
Shock Link @ Seatstay Pivot Spacer
Part Specification
6802 RS (1524F) Series Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
6802 RS (1524F) Series Full Complement Bearing - 24mm O.D. x 15mm I.D. x 5mm Width
6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Width
Alloy spacer - 20mm O.D. x 15mm I.D. x 3mm Width, Chamfered
Alloy spacer - 13mm O.D. x 10mm I.D. x 2mm Width, Chamfered
Alloy spacer - 20mm O.D. x 15mm I.D. x 3mm Width, Chamfered
Alloy spacer - 13mm O.D. x 10mm I.D. x 2mm Width, Chamfered
Torque in*lb
Part Specification
Alloy Axle - 15mm O.D. (23.5mm Head O.D.), M15 Thread x 64.5mm Shaft Length,
8mm Allen Hex Head
Alloy Nut - 23.5mm O.D x M15 Thread, 19mm socket (use 6-point 19mm socket only)
Alloy Bolt - M10 Thread x 28mm Shaft Length, 4mm Allen Hex Head
Alloy Axle - 15mm O.D. (23.5mm Head O.D.), M15 Thread x 71.5mm Shaft Length,
8mm Allen Hex Head
Alloy Nut - 23.5mm O.D x M15 Thread, 19mm socket (use 6-point 19mm socket only)
Alloy Bolt - M10 Thread x 28mm Shaft Length, 4mm Allen Hex Head
Alloy Bolt - M8 Thread x 47.5mm Shaft Length, 4mm Allen Hex Head
Alloy Bolt - M8 Thread x 55mm Shaft Length, 6mm Allen Hex Head
Alloy Nut - 13.5mm O.D x M8 Thread, 11mm socket
Part #
2.a
2.b
2.c
2.d
2.e
2.f
2.g
2.m
2.h
Qty.
1
1
2
1
1
2
1
1
1
Part Description
BB Pivot Axle
BB Pivot Nut
Dropout Pivot Bolt
Shock Link @ Frame Pivot Axle
Shock Link @ Frame Pivot Nut
Shock Link @ Seatstay Pivot Bolt
Lower Shock Eye Bolt
Upper Shock Eye Bolt
Lower Shock Eye Nut
200-230 B
200-230
70-90 B
200-230 B
200-230
70-90 B
100-120 B
100-120 B
120-140 B
