Spectra Precision RC601 User Manual

RC601UK REMOTE CONTROL
2
The Spectra RC601UK Infrared Remote Control enables the user to remotely (up to 30m), adjust
the following settings: Rotational speed, Scan angle & position, Manual Override (for single or
dual-axis grade/slope control). It cannot be used to turn the Laser ON or OFF (a feature not
available on any Spectra laser level system).
It is compatible with the Spectra LL100N, Spectra HV101 & Spectra LL300N only.
However, not all remote functions are available on all models of laser.
HV101 Scan Mode
(Stop Dot, 3°, 8°, 45°,
90° & 180° Line)
HV101 Rotational Speed Control.
Zero (Stop Dot), 50, 200, 600rpm
LL100N, HV101 & LL300N
Up / Down / Left & Right Arrows
(Grade / Slope Controls)
LL100N, HV101 & LL300N
Manual Override
(Disables Self Levelling!)

Spectra Precision RC601 Specifications

General

Brand	Spectra Precision
Model	RC601
Category	Remote Control
Language	English
