3. To mount the video monitor to a
transmitter, install the transmitter mount
as shown. The mount comes with two
adapters to fi t most transmitter neck
strap mounts. Once installed on the
transmitter, use the mounts built in
neck strap loop to mount a neckstrap if
desired.
4. Insert a micro memory card (not
included) in the slot on the side of the
video monitor. Press the card in until
it locks. To remove the card, press in
slightly and release until the card is
released.
Always insert the memory card before powering on the video monitor.
5. Unfold the sunshade as shown below.
6. Power on the video monitor and look for a clear channel. Clear channels will have
a consistent static background. Channels with interference will display horizontal
static lines. Select one of the clear channels.
7. Once you have chosen a clear channel on the monitor, select the same channel
on the video transmitter.
Available Frequencies (mHz)
Band CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
Band A 5865 5845 5825 5805 5785 5765 5745 5725
Band B 5733 5752 5771 5790 5809 5828 5847 5866
Band E 5705 5685 5665 5665 5885 5905 5905 5905
FS/IRC 5740 5760 5780 5800 5820 5840 5860 5880
RaceBand 5658 5695 5732 5769 5806 5843 5880 5917
