© 2013 Alliance Laundry Systems LLC AM11-0813R2
Speed Queen | 800-345-5649 | speedqueen.com/route
COIN/CARD WASHER-EXTRACTOR SPECIFICATIONS
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous
product improvements, design and specifications subject to change without notice. The quality management system of Alliance Laundry
Systems’ Ripon facility has been registered to ISO9001:2008.
CONTROLS
Quantum® Gold
- 27 cycle combinations
and 30 programmable
water levels
- PC/PDA programming
standard
- Premium cycles with
bonus vending pricing
modifier
- Time-of-day pricing
Quantum® Silver
- Nine combinations for
water and cycle
selections
- PC/PDA programming
standard
Model SCN020 SCN030 SCN040
Control Option Gold, Silver Gold, Silver Gold, Silver
Activation
Digital Coin Drop or
OEM Card Reader
Digital Coin Drop or
OEM Card Reader
Digital Coin Drop or
OEM Card Reader
Control Panel Selection Front Front Front
Capacity - lb (kg) 20 (9) 30 (13.6) 40 (18)
Width - in (mm) 26" (660) 29" (737) 30 5/8" (778)
Overall Depth - in (mm)* 30 1/4" (767) 34 9/16" (878) 39 3/4 (1009)
Height - in (mm) 43" (1092) 45" (1142) 47 1/4" (1199)
Cylinder Diameter - in (mm) 21" (533) 24" (610) 26 1/4" (667)
Cylinder Depth - in (mm) 13 3/4" (349) 16" (406) 20 1/4" (514)
Cylinder Volume - cu. ft. (liters) 2.76 (78.1) 4.19 (118) 6.34 (180)
Door Opening Size - in (mm) 11 5/8" (295) 14 5/16" (364) 16 1/4" (413)
Door Bottom to Floor - in (mm) 14 3/8" (365) 14" (356) 14 1/2" (368)
Water Inlet Connection - in (mm) 2 @ 3/4" (19) 2 @ 3/4" (19) 2 @ 3/4" (19)
Drain Diameter - in (mm) 1 @ 2" (52) 1 @ 2" (52) 1 @ 3" (76)
Drain Height to Floor - in (mm) 4 1/2" (114) 4 1/2” (114) 4 13/16” (122)
Motor Power Consumption - hp (kW) 1 (.75) 1 (.75) 2 (1.7)
Total # of Speeds 6, 9 6, 9 6, 9
Cylinder Speeds -
RPM (G Force)
Gentle 37 (0.4) 34 (0.4) 33 (0.4)
Wash
51 (.8) 48 (.8) 33 (0.4)
Distribution
92 (2.5) 86 (2.5) 82 (2.5)
Very Low
301 (27) 282 (27) 269 (27)
Low
518 (80) 485 (80) 464 (80)
Medium
580 (100) 542 (100) 518 (100)
**High
648 (120) 606 (120) 579 (120)
**Very High
710 (150) 664 (150) 635 (150)
**Ultra High 819 (200) 766 (200) 733 (200)
***Voltage Wires/
Circuit Breaker
- FLA
B 120/60/1 15-12 N/A N/A
X
200-208/220-
240/60/3/1/3
15-6 (1 Ph)
15-4 (3 Ph)
15-7 (1 ph)
15-5 (3 ph)
15-10 ( 1 ph)
15-6 (3 ph)
Q
200-208/220-
240/60/3/3
15-5 15-5 15-6
P 440-480/60/3/3 15-4 15-4 15-5
N 380-415/60/3/3 15-4 15-4 15-5
Shipping Dimensions
Approx - in (mm)
Width 29 1/2" (749) 32 1/2" (828) 34 1/4" (867)
Depth 34 5/8" (879) 39 13/16" (1014) 44 5/8" (1133)
Height 52 1/2" (1334) 54 1/2" (1389) 56 3/4" (1441)
Net Weight - lb (kg) 362(164) 491 (223) 592 (269)
Shipping Weight - lb (kg) 402 (181) 516 (234) 620 (281)
Slat Crate Shipping Weight - lb (kg) 476 (216) 588 (267) 846 (384)
****Agency Approvals
c
ETL
us
, CE
c
ETL
us
, CE
c
ETL
us
, CE
*Overall depth includes vacuum breaker to door handle.
**High, Very High, and Ultra High Spin Speeds are available on the Quantum Gold models only.
*** Circuit breaker and amp draw data shown are for models without electric heat. Consult factory for other configurations. Manufacturer strongly recommends using a circuit breaker instead of fuses. Use 3-pole circuit
breakers for 3-phase machines.
**** Agency approvals may vary depending on configuration. Consult factory for details. Steam connection requires 1/2” N.P.P.
