Specifications
Model available
Size available
Model and size
1.3
The power supply voltage has to be a transformer-isolated voltage
TECNICAL DATA CHARACTERISTICS
Supply voltage output 0,9 Vdc Input
PWM frequency 20Khz
Operating temperature 0/+45°C
Storage temperature -10/+70°C
Drift analog input 0,5uV/°C
Analog inputs (+/-VEL) +/-10Vdc max, impedance 20Kohm cad.
Current monitor output (CURR) +/- 8Vdc = Peak current
Velocity monitor output (T.P) +/- 8Vdc = max velocity
Power supply output (+5V) +5Vdc max 130 mA
Power supply output (+/-10V) +/-10Vdc max. 4mA
Encoder max. frequency 250Khz with level >+2,8/24Vdc min/max
Drive OK output NPN 50mA max.
Enable input >+8V/+30Vdc (min/max)
Band width (current) 2KHz
Band width (velocity) 150Hz
Minimum Inductance motor 200uH
Weight 0,35kg 10.6oz
Contaminants 2° or better (Norms EN60204 e EN50178)
Altitude
Up to 1000m without restrictions, from
1000 to 2000m power derating
1,5%/100m
Flammability rating 94V-0
Cover material, the PCB and the
electronic component meet 94V-0
CURRENT
Size Rated current (A) Peak current (A)*
2/4 2 4
4/8 4 8
7/14 7 14
10/20 10 20
*Peak current during 2 sec
POWER SUPPLY
Model 60 20 - 84 Vdc* 60Vdc **
Model 110 30 - 130 Vdc* 100Vdc **
Model 140 40 - 184 Vdc* 140Vdc **
* Power supply min/max **Typical
Max size available for SMB110 7/14A
Max size available for SMB140 4/8A
