MODEL MAX.POWER GUIDE NO. RECYCLE POWER RATIO DIAL TOTAL OUTPUT SPECIAL FEATURES WEIGHT/SIZE
(Watt-secs) 35°-90° (secs) CHANNELS COMB. DOWN VARIATIONS
______________________________________________________________________________________________________________________________________________________________________________________________________
Explorer 1500 1500 540 3.5 2 N/A continuous to -5 stops continuous BatteryPower, Ratio, Dial-down power, Slave, Universal Voltage input 24.9lbs / 9.5x5.4x11.7” **
405 400 290-160 1.3 2 6 9 54 Ratio, Dial-down power 5lbs / 6.5x4.375x7.2” **
1005 1000 408 1.6 3 12 10 120 Ratio, Dial-down power, Slave 7.9lbs / 8x4.375x9.5” **
1205cx LV 1200 500-270 0.9 3 21 9 189 Ratio, Dial-down power & model lamp 15lbs / 6.4x8.8x10”
2401sx 2400 710-380 2.0 3 53 NA 53 Ratio, LV Trigger, Forced air cooling 27lbs / 9x12x14”
2403cx LV 2400 710-380 2.0 3 53 10 530 Ratio, Dial-down power & optional remote 28lbs / 9x12x14”
2405cx LV 2400 710-380 2.0 3 25 9 225 Ratio, Dial-down power & model lamp 23lbs / 6.4x8.8x13”
4803cx LV 4800 1000-540 4.0 3 27 10 270 Ratio, Dial-down power & optional remote 43lbs / 9x14x14”
______________________________________________________________________________________________________________________________________________________________________________________________________
*Guide # calculated at ISO 100, in ft. w/202VF Light, 11.5” reflector forward (35°) & back (90°) positions (except 4803, with 206VF light) **including handle
MODEL MAX.POWER FLASH TUBES SPECIAL CHARACTERISTICS
(Watt-secs) (qty.-regular or color corrected)
_______________________________________________________________________________
102 2400 1 - MW8QV or 1 - MW8QVC economical, general purpose
103 2400 1 - MW9Q or 1 - MW9QC lightweight, compact
202VF 2400 1 - MW20QV or 1 - MW20QVC variable focus, modular construction
206VF 4800 1 - MW40QV or 1 - MW40QVC variable focus, high output
105 (2 cable) 4800 4 - MW24Q or 4 - MW24QC shortest flash duration
105 (4 cable) 9600 4 - MW24Q or 4 - MW24QC shortest flash duration, highest output
________________________________________________________________________________
Note: All Speedotron light units are fan-cooled and accept a 250W model lamp (except the low profile 103).
FLASH DURATION (watt-seconds per light unit)
MODEL Watt-secs: 9600 4800 2400 1200 600 300
_____________________________________________________________________________________
102 ----- ----- 1/225 1/400 1/670 1/1250
103** ----- ----- 1/450 1/770 1/1300 1/1800
202VF ----- ----- 1/300 1/500 1/900 1/1425
206VF ----- 1/175 1/300 1/500* 1/900* 1/1425*
105 (2 cable) ----- 1/600 1/1175 1/2000 1/3570 1/5000
105 (4 cable) 1/400 1/600 1/1175 1/2000 ----- -----
_____________________________________________________________________________________
If power is reduced by using the dial-down knob, durations will remain the same. All durations tested in accordance with ANSI PH3.40
Section 2; “The time interval from the instant the flash reaches one-half of its peak intensity to the instant it decays to the same value”.
*These power levels are reached by the use of the 14202 adapter cable & a standard outlet.
**Flash duration of 103 light unit using the 405 power supply: 400Ws = 1/500sec.;
and using the 1005 power supply: 800Ws = 1/300sec., 400Ws = 1/500sec.
LIGHT UNITS
POWER SUPPLIES
technical specifications
