EN
3
SPMFC6250HX
Type FC6250HX Helicopter Flybarless System
Dimensions (L × W × H) 42.5 x 24 x 13.6mm (1.67 x 0.94 x 0.54in)
Weight 13g (0.46oz)
Voltage Range 4.8V – 8.4V
Introduction
The Spektrum™ FC6250HX flight controller is the heart of your radio control
helicopter experience. As a 3-axis stability system for your flybarless helicopter,
the FC6250HX can be set up and tuned using your Spektrum transmitter
as a forward programming interface. All the flight controller settings can be
programmed through your transmitter. Using AS3X and SAFE technology, the
FC6250HX offers self-leveling beginner modes, as well as pro-level flight
performance.
Add a Spektrum Smart ESC to your heli to further expand integrated features
with no extra wires or sensors. When the flight controller detects a Smart ESC
connection, it feeds a telemetry stream to the transmitter, putting live battery
data power into your hands.
The FC6250HX can also be programmed, updated, and backed up using
the Spektrum USB Programmer and PC programmer application. Visit the
SPMFC6250HX product page at HorizonHobby.com for more information.
Features
• Supports two DSMX remote receivers
• User configurable SAFE Panic Recovery and Stability Flight Modes
• Easy to use Forward Programming for setup and gain adjustments from
compatible Spektrum Transmitters
• Smart Technology ready for Smart ESC and Smart Battery telemetry
• Supports DX, iX, and NX series transmitters
• Supports Digital and Analog servos
• 70Hz to 560Hz Adjustable Servo Frequency (760μs and 1520μs center)
Contents
• (1) Helicopter Flybarless Control System (SPMFC6250HX)
• (1) DSMX SRXL2 Serial Receiver with Telemetry (SPM4651T)
• (1) 4-Pin ZH to 3-Pin Servo Connector
• (1) 3-Pin Male to 3-Pin Male adapter
• (1) Product Manuals (SPMFC6250HX and SPM4651T)
• (2) Gyro Mounting Pad (SPMA3032)
FC6250HX to 4651T Cable
4651T Update Cable
