4 I Spengler
PREPARATION FOR USE
Installing/Replacing Batteries
1. Insert the batteries into the battery compartment
matching correct polarities "+" and "-".
2. Replace all batteries if the low battery indicator
appears.
3. Remove the batteries if the unit will not be used for
a long period of time.
NOTE: It is recommended that the same type of
alkaline batteries be used to avoid incompatibility.
AC Adapter (optional)
It is recommended to use an AC adapter(output 6V
DC/0.8A) to operate the device.
1. Connect the AC adapter to the socket located on
the right side of the device as shown in the figure.
Attaching the Pressure Cuff to the Unit
1. Connect the tube connector to the socket of the
unit as shown in the figure.
Attaching the Pressure Cuff around the Arm
1. Wrap the cuff around bare-skinned left arm.
To Next Page
