5
Panther/Cougar/Puma SCBA Operation Manual
ITEM P/N DESCRIPTION
962600 COMPASS Integrated PASS Device
963820 COMPASS Buddy Breather Kit
963850 COMPASS SAR Attachment Kit
963702 COMPASS and Buddy Breather Kit
963703 COMPASS and Buddy Breather with SAR Attachment Kit
962700 DoublePASS Remote Alarm Module
ITEM P/N DESCRIPTION
Fit Testing Accessories, Qualitative (Cougar and Puma)
193140 IAA/Banana Oil Fit Test Kit
100100 Organic Vapor Cartridge, Box of 6 (For Use with P/N
193140 Fit Test Kit)
193138 Replacement IAA Solution, 1 oz.
Fit Testing Accessories, Quantitative (Cougar Only)
962920 Fit Test Kit, SCBA/APR Adapter (Requires the P/N
962900 Kit, APR Adapter)
962925 Fit Test Kit, Rell
105005 P100 Filters, Box of 10
962848 Probed Lens, TwentyTwenty Plus Facepiece
* Shown in Figure 1
IV. DESCRIPTION
The Panther/Cougar/Puma SCBA provides the wearer
with respiratory protection in hazardous environments,
and may be used for entrance into and escape from
atmospheres that are immediately dangerous to life
or health (IDLH). The Panther is an NFPA-compliant
SCBA and may be used for re ghting. The Cougar
and Puma are industrial SCBAs and must not be used
in the presence of high heat or open ames.
NOTE
The Panther SCBA meets all requirements •
of the NFPA 1981 Standard, 2002 Edition,
Open-Circuit Self-Contained Breathing Ap-
paratus for Fire and Emergency Services.
See NFPA 1500, Standard on Fire Depart-•
ment Occupational Safety and Health Pro-
gram for proper use of SCBAs in the work
environment.
A. Backpack and Cylinder
The backpack consists of a lightweight contoured 1.
polymer frame with a built-in carrying handle. The
cylinder is attached by a lightweight webbing-style
band. The Panther harness is made of Kevlar/No-
mex straps. The Cougar/Puma harness is made of
nylon straps. The chest-mounted pressure gauge
is mounted on the right shoulder strap, and the
intermediate pressure hose is routed over the left
shoulder. The gauge indicates the cylinder pres-
sure once the cylinder valve has been opened.
The chest-mounted pressure gauge is optional
for the Panther SCBA. It is included with the Cou-
gar and Puma SCBAs, but is optional for the Cou-
gar if a Heads-Up Display is installed.
The air cylinder is a composite construction with 2.
an aluminum inner liner overwrapped by a nonme-
tallic ber, and has a maximum working pressure
of 2216 or 3000 psig (low pressure) in 30-minute
duration, or 4500 psig (high pressure) in 30-, 45-,
ITEM P/N DESCRIPTION
CYLINDER/VALVE ASSEMBLY
TwentyTwenty Plus Facepiece Accessories
962869 Neck Strap Kit
962900 Kit, APR Adapter
962260 Spectacles Kit
962266 Large Nose Cup Kit
962265 Medium Nose Cup Kit
962264 Small Nose Cup Kit
960038 Headnet
™
Kit
964171 Radio Communication System
964172 SmallTalk
®
Plus Voice Amplication System
964173 Radio Communication/SmallTalk Plus Voice Amplication
System
964165 Remote Push-to-Talk Kit
Pressure (psig) Duration
(minutes)
Wrap Material
916103 2216 30 Hoop Glass
915140 2216 30 none Aluminum
915170 2216 30 Full Glass
915165 4500 30 Hoop Glass
916173 4500 30 Full Glass
916140 4500 45 Full Glass
915182 4500 60 Full Glass
916123 3000 30 Full Carbon
917130 2216 30 Full Carbon
917131 4500 30 Full Carbon
917145 4500 45 Full Carbon
917160 4500 60 Full Carbon
General Accessories
940118 Protective Mask Bag
140096 Mask Wipes (100 ea.)
951015 Anti-fog Solution (1 oz.)
951016 Anti-fog Solution (16 oz.)
981806 Anti-fog Wipe
980200 Suit Pass-through Kit
946935 Cylinder Sleeve for LP Hoop-wrapped Cylinder
946937 Cylinder Sleeve for HP Hoop-wrapped Cylinder
941256 Cylinder Sleeve for LP Carbon Cylinder
941257 Cylinder Sleeve for 3000 psig Carbon Cylinder
941258 Cylinder Sleeve for HP 30 Minute Carbon Cylinder
941259 Cylinder Sleeve for HP 45 Minute Carbon Cylinder
941261 Cylinder Sleeve for HP 60 Minute Carbon Cylinder
968670 Chest Strap Kit
964867 Utility D-ring
930801/
02/04/
61/62/
64/70
Air Supply Hoses,3/8 inch
930810 Foster Coupler Kit
930820 Schrader Coupler Kit
930830 Hansen Coupler Kit
945007 Hansen Coupler Kit, Stainless Steel
961438 SuperCharge Fill Hose, Handwheel and Nipple, 2216
psig, 4 foot
961546 SuperCharge Fill Hose, Handwheel and Nipple, 2216
psig, 10 foot
961549 SuperCharge Fill Hose, Handwheel and Nipple, 2216
psig, 20 foot
961439 SuperCharge Fill Hose, Handwheel and Nipple, 3000
psig, 4 foot
961547 SuperCharge Fill Hose, Handwheel and Nipple, 3000
psig, 10 foot
961562 SuperCharge Fill Hose, Handwheel and Nipple, 3000
psig, 20 foot
961441 SuperCharge Fill Hose, Handwheel and Nipple, 4500
psig, 4 foot
961548 SuperCharge Fill Hose, Handwheel and Nipple, 4500
psig, 10 foot
961563 SuperCharge Fill Hose, Handwheel and Nipple, 4500
psig, 20 foot
965110 Over-the-Shoulder Buddy Breather Kit
965119 Over-the-Shoulder Buddy Breather Kit with Check Valve
(for use with P/N 965122 Kit)
965122 Air Line Adapter Kit
