To Next PageTo Next PageWhat to do if the Sperry Marine 5016-CC shows a stepper sync timeout error?
If you encounter a stepper sync timeout on your Sperry Marine Repeater, it indicates that synchronization has failed. First, try re-initiating the synchronization. If the issue continues, cycle the power. Should the error persist after several synchronization attempts, the repeater might need to be returned to Sperry Marine for exchange.
What to do if my Sperry Marine Repeater shows an error in received NMEA message?
If your Sperry Marine Repeater displays 'error in received NMEA message,' it means the received data is either out of range or not properly formatted. To resolve this, verify that all messages contain proper data.
What does 'timeout gyro heading' mean on my Sperry Marine 5016-CC?
If the Sperry Marine Repeater displays a 'timeout gyro heading' error, it signifies that the gyro heading data is either lost or invalid while the gyro is the active source. To fix this, ensure that valid gyro heading data is present.
What does 'timeout magnetic heading' mean on my Sperry Marine 5016-CC Repeater?
If the Sperry Marine Repeater displays a 'timeout magnetic heading' error, this indicates that the magnetic heading data is either lost or invalid while the magnetic compass is the active source. To resolve this, check that valid magnetic compass heading data is present.
What does 'timeout thd heading' mean on my Sperry Marine 5016-CC?
If your Sperry Marine Repeater shows a 'timeout thd heading' error, it means the THD heading data is lost or invalid while THD is the active source. You should check that valid THD heading data is present.
Why does my Sperry Marine Repeater say 'updaterate gyro heading too low'?
If the Sperry Marine Repeater displays 'updaterate gyro heading too low', it means the gyro heading update rate is less than 1 Hz. To fix this, check gyro messages for invalid data or checksum faults and increase the update rate at the source.
Why does my Sperry Marine 5016-CC Repeater say 'updaterate magnetic heading too low'?
If your Sperry Marine Repeater shows 'updaterate magnetic heading too low', it means the magnetic heading update rate is less than 1 Hz. Check the magnetic heading messages for invalid data or checksum faults. Also, increase the update rate at the source.
Why does my Sperry Marine Repeater say 'updaterate thd heading too low'?
If your Sperry Marine Repeater displays 'updaterate thd heading too low', it means the THD heading update rate is less than 1 Hz. You should check the THD messages for invalid data or checksum faults and increase the update rate at the source.
What causes a 'stepper power' error on a Sperry Marine Repeater?
If your Sperry Marine Repeater indicates a 'stepper power' issue, it signifies that the stepper motor phase supply voltage is too low. Verify the actual voltage from the 24 VDC supply.
What to do if my Sperry Marine 5016-CC Repeater displays 'no message received'?
If your Sperry Marine Repeater shows 'no message received', it indicates that there is no data at the input. Verify that valid data is present at the input.
Important safety guidelines for users operating the compass repeaters.
Critical safety precautions for personnel performing maintenance or servicing.
Table detailing error conditions, blink codes, and corrective actions.
Installation procedures for the Bearing Repeater with different mounting options.
Installation instructions for Steering and Magnetic Heading Repeaters in consoles.
Procedures for installing the Bulkhead Repeater directly or with a bracket.
Step-by-step guide for configuring repeaters using the SUSI application.
Detailed explanation of settable parameters like RCS Type, Protocol, Baudrate, etc.
How to access and interpret error logs using the SUSI application.
Process for updating the repeater's firmware using the SUSI application.
General| Model | 5016-CC |
|---|---|
| Manufacturer | Sperry Marine |
| Power Supply | 24 VDC |
| Display | LCD |
| Operating Temperature | -15°C to +55°C |
| Humidity | Up to 95% non-condensing |
| Type | Repeater |
| Interface | NMEA 0183 |
| Storage Temperature | +70°C |
