COLOR CODE
Power–blue
Input–pink
Output–green
Wire– orange
You always need a blue and a
green; pink and orange are
optional, in between.
Ages14 to
synth speaker
The synth speaker amplifies your sonic explorations!
You can control the volume with a dial at the front
of the module. It also features an output jack that
you can connect to headphones, an amplifier, or a
computer. The speaker is connected with 3M
TM
Dual
Lock
TM
so it can be removed from the circuit board.
To reattach, hold module and press together firmly.
More info littleBits.cc/Bits/synth-speaker
try this circuit
Start with a
blue power
module and
turn it on.
Switch the
“waveform”
and hear the
timbre change.
Rock out to the
sweet sounds
from your synth
speaker!
power oscillator
ttg“”
atu
synth speaker
