Ages 8 to
COLOR CODE
Power–blue
Input–pink
Output–green
Wire–orange
You always need a blue and a
green; pink and orange are
optional, in between.
FILTER
The filter has the biggest effect on the sound’s char-
acter or “timbre.” It affects the timbre by changing
the relative volume of certain frequencies in the
sound. Use it to give the impression that a sound
is “brighter” (more high frequencies) or “darker”
(more low frequencies). The “cutoff” knob sets the
frequency to be emphasized, and the other controls
“peak”, or intensity of the filter. If the “peak” is turned
up all the way, the filter turns into an oscillator!
MORE INFO littleBits.cc/Bits/filter
TRY THIS CIRCUIT
Start with a
blue power
module and
turn it on.
Set the random
module to
“noise” mode.
Adjust the “cutoff”
and “peak”
settings to change
the sound.
power random filter
adjust volume
synth
speaker
