Ages 8 to
COLOR CODE
Power–blue
Input–pink
Output–green
Wire–orange
You always need a blue and a
green; pink and orange are
optional, in between.
MIX
The mix module allows you to combine two inputs
and send them to a single output. It also has a
level control for each of its inputs — that’s where
the mixing comes in. Use it to play two oscillators
on a single speaker!
MORE INFO littleBits.cc/Bits/mix
TRY THIS CIRCUIT
power mixsplit
oscillator
oscillator
Start with a
blue power
module and
turn it on.
Turn the mix
controls up so
you can hear
the oscillators.
Adjust the
“pitch” of both
oscillators.
adjust volume
synth
speaker
