COLOR CODE
Power–blue
Input–pink
Output–green
Wire – orange
You always need a blue and a
green; pink and orange are
optional, in between.
double and
The double AND module is a logic gate with
two inputs. Just like its name implies, it sends an
on signal from its output only when input one and
input two are both receiving an on signal.
More info littleBits.cc/Bits/double-and
Try This circuiT
Start with a
blue power
module and
turn it on.
Activate both
pink input
modules.
Watch the double
AND module
aect the output
module.
power branch button
slide
switch
LED
double AND
wire
