COLOR CODE
Power–blue
Input–pink
Output–green
Wire – orange
You always need a blue and a
green; pink and orange are
optional, in between.
WIRELESS tRanSmIttER
The wireless transmitter sends a signal to your wireless
receiver and activates your circuit remotely! The three
channels on the transmitter and receiver correspond
to each other and can be used simultaneously. The
module can transmit its signal to a distance of about
100’ indoors. Multiple wireless receivers can be
used with a single transmitter, but only one transmitter
can be used in proximity to another transmitter.
moRE Info littleBits.cc/Bits/wireless-transmitter
tRy thIS cIRcuIt
Cs
l d
Start with a
blue power
module and
turn it on.
Adjust the input
modules.
See the output
modules connect-
ed to the wireless
receiver turn on.
power dimmer
wireless
transmitter
slide
switchfork
button
