COLOR CODE
Power–blue
Input–pink
Output–green
Wire – orange
You always need a blue and a
green; pink and orange are
optional, in between.
Nor
The NOR module is a logic gate with two inputs.
As its name suggests, it sends an on signal only
when neither input is receiving an on signal. In oth-
er words, it’s the exact opposite of the OR module.
More iNfo littleBits.cc/Bits/nor
Try This circuiT
Start with a
blue power
module and
turn it on.
Leave both
input modules
o.
Watch the
NOR module
aect the out-
put module.
power branch button
slide
switch
LED
NOR
wire
