COLOR CODE
Power–blue
Input–pink
Output–green
Wire – orange
You always need a blue and a
green; pink and orange are
optional, in between.
NaNd
The NAND module is a logic gate with two inputs.
Think of it as “not and.” The NAND module will
always send an on signal unless both input one
and input two are receiving an on signal. It’s the
exact opposite of the AND module.
More iNfo littleBits.cc/Bits/nand
Try This circuiT
Start with a
blue power
module and
turn it on.
Activate only
one input module
or leave both
inputs o.
Watch the
NAND module
aect the output
module.
power branch button
slide
switch
LED
NAND
wire
