Ages 8 to
COLOR CODE
Power–blue
Input–pink
Output–green
Wire – orange
You always need a blue and a
green; pink and orange are
optional, in between.
xor
The XOR module is a logic gate with two inputs.
Think of it as “exclusive or,” meaning that it sends
an on signal when it’s receiving an on signal exclu-
sively from one input or the other, but not both.
More info littleBits.cc/Bits/xor
Try This circuiT
Start with a
blue power
module and
turn it on.
Activate only
one input
module.
Watch the XOR
module aect
the output
module.
power branch button
slide
switch
LED
XOR
wire
