1. Attach rockwall boards and rocks as shown.
#8 x 2.25 Wood Screw X32
Begin here - Flush
under rail
Parts Required:
130 X8
Rocks with Hardware X5
Step 1 - Use rock to mark holes
onto rockwall board in pattern shown
Step 2 - Drill .31" [7.9] holes through
boards
Step 3 - Attach rocks using hardware
in rock bag (T-nut, hex bolts and washers)
Flush at ends
3.125 [79.4]
3.125 [79.4]
3.125 [79.4]
3.125 [79.4]
Boards are flush at seams
All spaces
1. Attach rockwall boards and rocks as shown.
Parts Required:
130 X8
Rocks with Hardware X5
To Next Page
