Spimbey 2004 - Table Assembly

TABLE
8
136
2x
124
3x
139
137
138
1. Locate and attach parts as shown.
#8 x 1.75" Wood Screw X13
Parts Required:
124 X3 138 X1
136 X2 139 X1
137 X1
21.00 [533.4]
Two places
#8 X 2.50 Wood Screw X4
Flush
Locate 139 flush atbothends
and IOXVKWRtop RI
1RWH>@KROHORFDWLRQ
Locate 124 flush at top
and centered on holes.#8
X 2.50 Wood Screw X6
IURPEHKLQG
#8 X 3.00 Wood Screw X4
.687
[17.5]
ROCKWALL TO
THIS SIDE
(SOME BOARDS
REMOVED FOR
CLARITY)
Table LVflush to
EDFNtopand
ends of 139
1. Locate and attach parts as shown.
Parts Required:
124 X3
136 X2
137 X1
138 X1
139 X1
