Spimbey 2004 - Ladder Assembly and Attachment

LADDER
9
1. Layout and attach parts as shown
Parts Required:
115 X 4
116 X 1
117 X 1
118 X 1
16x
#8 x 2.50 Wood Screw
4.500
[114.3]
117
115
115
115
115
116
Center on rail
118
301
118
4x
2x
Flush
#8 x 2.50 Wood Screw
5/16 x 1.50
Hex Bolt
5/16 T-Nut
5/16 Flat Washer
5/16 Lock
Washer
