LADDER
10
1. Locate and install parts as shown.
2. Locate ladder centered in opening and drill two holes for the ladder brackets
Parts Required:
Ladder Assembly X1
1. Locate and install parts as shown.
2. Locate ladder centered in opening and drill two holes for the ladder brackets
Center brackets
on rail
Mark center of hole and
drill a
3
8
" hole through rail
2 - Holes
5
16
x 1.25" Hex Bolt X2
5
16
" Lock Washer X2
5
16
" Flat Washer X2
5
16
" T-Nut X2 on opposite side
Parts Required:
Ladder Assembly X1
Center ladder
in opening
