Spimbey 2004 - Baluster Installation

BALUSTERS
11
1. Locate and attach parts as shown
Parts Required:
111 X15
111
15x
1. Locate and attach parts as shown
Parts Required:
111 X15
ROCKWALL
SLIDE
LADDER
3.500 [88.9]
All spacing between
balusters is 3.00 [76.2]
3.500 [88.9]
3.000 [76.2]
2.000 [50.8])URPHQG
RIWRSUDLO
3.000 [76.2]
All spacing between
balusters is
3.00 [76.2]
#8 x 1.38 Wood Screw X60
Balusters are flush at top
and bottom of rails
Part 111 X15
ROCKWALL
SLIDE
LADDER
3.500 [88.9]
All spacing between
balusters is 3.00 [76.2]
3.500 [88.9]
3.000 [76.2]
2.000 [50.8]
3.000 [76.2]
All spacing between
balusters is
3.00 [76.2]
#8 x 1.38 Wood Screw X60
Balusters are flush at top
and bottom of rails
