ROOF
13
1. Attach (2) brackets to a roof section as shown.
2. Make (4) Roof/Bracket Assemblies.
Parts Required:
ROOF 1 X4
4.50"
23.00"
1. Attach (2) brackets to a roof section as shown.
2. Make (4) Roof/Bracket Assemblies
ATTACH BRACKET TO X4 ROOF PANELS
Part 304 X2
#8 x
3
4
" Truss Head Screw
X8
Attach all brackets with bend
in-line with edge of roof frame
Parts Required:
ROOF 1 X4
9 ROOF
ATTACH BRACKET TO X4 ROOF PANELS$66+2:1
$//%5$&.(76727+(6$0(6,'(
%UDFNHW;
To Next Page
