ASSEMBLE BEAMS
17
1. Locate and install parts as shown.
Parts Required:
224 X1
40.19" [102.1]
14.00" [35.6]
1
4
x 4.25" Hex Bolt X1
1
4
Lock Washer X1
1
4
Flat Washer X1
1
4
x 5.50" Hex Bolt X1
1
4
Lock Washer X1
1
4
Flat Washer X1
From this side in end holes X4
1
4
T-Nut X1
From this side in end holes X4
1
4
T-Nut X1
From this side
1. Locate and install parts as shown.
Parts Required:
224 X1
Note hole locations
224
