Spimbey 2004 - Page 30

BEAM PLATES
16
40.19"
[102.1]
14.00"
[35.6]
5
16
T-Nut X4
5
16
Lock Washer X4
5
16
x 1.50" Hex Bolt X4
Important - insert bolt into INSET hole
in plate and hole in beam
X2
Plate #300
X4
This hole lines up with
hole in beam
5
16
Flat Washer X4
1. Locate and install parts as shown.
Parts Required:
300 Plate X4
BEAM PLATES
Important - insert bolt into END hole
in plate and hole in beam
X2
This hole lines up with
hole in beam
Note hole locations
1. Locate and install parts as shown.
Parts Required:
300 Plate X4
From this side
