Spimbey 2004 - Page 33

19
5
16
T-Nut X2
5
16
x 4.25" Hex Bolt X2
5
16
Flat Washer X2
5
16
x 2.00" Hex Bolt X2
5
16
Flat Washer X2
5
16
Lock Nut X2
5
16
Flat Washer X2
Bolts in these holes
1. Locate and install parts as shown.
Parts Required:
Beam Assembly X1
A-Frame Assembly X1
14.00" [35.6]
40.19" [102.1]
IMPORTANT - PLATES ARE
INSET AT THIS END.
IMPORTANT - Note hole locations
100°
Inset
1. Locate and install parts as shown.
Parts Required:
Beam Assembly X1
A-Frame Assembly X1
