Spimbey 2004 - Page 38

24
1. Locate and install parts as shown.
2. Make sure to orient hangers as shown.
220 X1
221 X1
Swing Hangers X6
SWINGS ATTACHED
1. Attach swings as shown to minimum heights shown.
Parts Required:
Swings X2
Trapeze X1
SWINGS ATTACHED
8.00 [20.3]
Minimum from ground
53.00 [134.6]
Minimum from
ground
Hang swings from hanger as shown
Adjust height using chain
1. Attach swings as shown to minimum heights shown.
Parts Required:
Swings X2
Trapeze X1
