Model Line Dia
Max SWL
(each line)
Fasteners
XAS0612/1 6-12mm (1/4-1/2”) 575kg (1250Ibs) 2 X M6 CSK (2 X 1/4” CSK)
XAS0612/2 6-12mm (1/4-1/2”) 575kg (1250Ibs) 4 X M6 CSK (4 X 1/4” CSK)
XAS0612/3 6-12mm (1/4-1/2”) 575kg (1250Ibs) 6 X M6 CSK (6 X 1/4” CSK)
XAS0408/1 4-8mm (5/32-5/16”) 450kg (990Ibs) 2 X M6 CSK (2 X 1/4” CSK)
XAS0408/2 4-8mm (5/32-5/16”) 450kg (990Ibs) 4 X M6 CSK (4 X 1/4” CSK)
XAS0408/3 4-8mm (5/32-5/16”) 450kg (990Ibs) 6 X M6 CSK(6 X 1/4” CSK)
SIZE
SAME HOLE SPACING AS THE XA CLUTCH
TEMPLATE FOR SINGLE XAS UNIT
WINCH END
SPECIFICATION TABLE
TEMPLATE - ACTUAL
