IM-P382-01 CH Issue 4
7
4. Pre-commissioning checks
These temperature control systems have been designed and manufactured to the highest
industrial standards. In order that they function correctly, please observe the following points
and then proceed with the 'Display adjustment' in Section 5 for adjusting to the desired set
temperature.
Factory temperature setting
In order to avoid accidental damage due to exposure of extreme temperatures, the unit is
factory adjusted to its highest set temperature. This value will vary according to the data
shown in Table 2.
Overtemperature protection
In the event that the overtemperature protection is exceeded by the values shown, serious
damage will occur and the warranty will be invalidated. Before commissioning this unit, please
ensure that the system temperature cannot exceed the overtemperature protection value.
Table 2
Metric
Self-acting temperature Range
Temperature Factory
Overtemperature
control system no.
adjustment setting
protection
range (°C)
1 -15 to +50 50°C
SA121, SA1219 and SA123 2 +40 to +105 105°C
55°C over set
3 +95 to +160 160°C value to 190°C
SA122
1 -20 to +120 120°C
maximum
2 +40 to +170 170°C (215°C maximum
SA128
1 -20 to +110 110°C for the SA123)
2 +40 to +170 170°C
Imperial
Self-acting temperature Range
Temperature Factory
Overtemperature
control system no.
adjustment setting
protection
range (°F)
1 +5 to +125 125°F
SA121, SA1219 and SA123 2 +105 to +225 225°F
130°F over set
3 +205 to +325 325°F value to 374°F
SA122
1 -5 to +240 240°F
maximum
2 +106 to +340 340°F (420°F maximum
SA128
1 -5 to +230 230°F for the SA123)
2 +106 to +340 340°F
