MAINTENANCEANDFAULTFINDINGPROCEDURES



WARNING:ALWAYSISOLATEUNITFROMTHEELECTRICALSUPPLYBEFOREATTEMPTING

ANYREPAIRSORMAINTENANCE.



General:



 Every150hours:Washinletfilterwithmilddetergentanddr y.

Filtermustbethoroughlydrybeforereplacingandmustnotbeoiled.

 Every150hours:Checkthat

allairlinesaretightandingoodco ndition.

 Every300hours:Replacefuelfilter.

 Every600hours:Drainthefueltankandflushitusingcleanfuel.



PressureSetting:



 Onceperseasonorwhennecessary,adjustpressuresettingasperprocedurebelow.

‐Thepressure

settingmustbeadjustedtoachievearedexitconewithNOflameexiting

theheater.

‐Aredexitconewillensureodourfreeoperation.



Toadjustpressuresetting:



1. Startandrunheateruntilstableoperatingtemperatureisachieved.

2. Withheaterrunning,loosenlocknutA.

3. Set

correctpressurebyadjustingvalveB.

‐Screwing the valve clockwise will increase the fuel flow  andachieveamoreredexit

cone.

‐Ifflamesareexitingtheheate r,turnthevalveanti‐clockwisetoreducefuelflow.

4. Oncesuitablepressurehasbeenset,tightenlocknutA.



LockNutA

PressureValveB
