Pneumatic
Rotary Hammer Drill
2 2404 0010, 0030, 0040
Maschinenfabrik GmbH
Spitznas Maschinenfabrik GmbH, Fellerstr.4, D-42555 Velbert, Tel: +49(0)2052 605 0, Fax: +49(0)2052 605 29, www.spitznas.de
Translation of the original manual,
compiled: 25.05.12
224040010_30_40_BA_en_Version_01 Page 12 of 13
Spare Parts and Accessories
Only original spare parts may be used. There is no warranty for damages and liability is
disclaimed, if non-original spare parts and accessories are used.
The repairing of the machine is allowed authorized expert companies only.
The accessories applicable with our machine are listed in our brochure.
Troubleshooting
Problem Cause Remedy
a Machine does not
start
Air not connected
Connect and open air line
b Machine rotates too
slowly
Operating pressure too low
Increase operating pressure (on the
machine) to 6 bar
c Gearbox makes strong
noise
Contact authorized expert company
d Other problems Contact authorized expert company
D e c l a r a t i o n o f C o n f o r m i t y
as defined in the European Union Machine Directive 2006/42/ EC
for usable machines
We, the company
SPITZNAS Maschinenfabrik GmbH, Fellerstraße 4, 42555 Velbert– Langenberg,
declare that the following product
Description: Pneumatic Rotary Hammer Drill
Model 2 2404 0010/ 2 2404 0040
complies with the provisions of the European Union Machine Directive 2006/42/ EC
and 94/9 EC (Atex 95 – group II, category 2, G c T6) and conforms to the following standards or
standardized documents: DIN EN ISO 12100
DIN 24063
DIN EN 1127
DIN EN 13463
According to section 8 (1) ii) of the directive 94/9/EC technical documentation is deposited under
reference No. 968/Ex-AB 429/04 at the following office:
TÜV Rheinland Industrie Service GmbH
Haumannplatz 4, 45130 Essen
(Registration No. 0035 for the scope of
the Directive 94/9/EC)
Name of the authorized person for documentation: Mr. Simon Witt
Address of the authorized person for documentation: see manufacturer’s address
42555 Velbert, 25.05.12
