Use
Intended Use
The machine is designed for drilling into concrete and masonry. The machine is intended to be
used by professional operators. Only authorized and trained personnel may use, maintain and
repair the machine. The personnel has to be especially instructed on the potential dangers. The
working environment can be: construction site, factory, renovation, rebuilding and building.
Manipulation or modifications to the machine are not allowed. Observe the instructions regarding
the operation, care and maintenance in the operation instruction. Dangers can come from the
machines and the auxiliary materials, if improperly handled or used.
Improper Use
Any use deviating from the intended use as described is considered to be improper use.
Working without personal protection equipment.
Danger Zones
Operational
condition
----------------
Life phase
Normal function Malfunction Improper use Expected use
Transport Transport of the
machine in an
inoperable
condition
Drop of the
machine
Transport of the
machine in an
operable condition
unknown
Machine only
works with
actuated valve
Machine runs
without actuated
valve
Switch is blocked
in actuated
condition
unknown Operation
Machine moves
the tool
Tool blocks unknown unknown
Maintenance Operation at a
maintenance unit
Breakdown of the
machine
unknown unknown
