Spitznas 2 2406 0010 - Cooling Pipe Assembly Parts List

Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
12
of
1
4
Spare Parts List
Description: Part and drawing number:
Cooling pipe, assy. 2 2404 9200
Item Qty. Description Part and Drawing no. Remarks
1 1 Flushing pipe 2 2404 9210
2 1 Reducing nipple 9 2203 0310
3 1 Ball valve hexagonal 9 2014 0900
4 1 Gasket 9 2126 0100
5 1 Hose nozzle 9 2109 0920
