Spitznas 2 2406 0010 - Page 14

Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
13
of
1
4
Spare Parts List
Description: Part and drawing number:
Cooling pipe, assy. 2 2404 9200
