Spitznas 2 2406 0010 - Output Unit Assembly Parts List

Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
4
of
1
4
Spare Parts List
Description: Part and drawing number:
Output unit, assy. 2 2426 7000
Item Qty. Description Part and Drawing no. Remarks
401 1 Gearbox housing 2 2404 4010
402 1 Tension sleeve 2 2404 8100
403 1 Sliding sleeve 2 2404 7130
404 1 Bushing 2 2404 7140
405 1 Feather key 9 1506 9240
407 1 Shifter sleeve, assy. 2 2404 8940
408 1 Cylinder, assy. 2 2404 8920
409 1 Impact piston 2 2404 4540
410 1 Nut 2 2404 8240
411 1 End piece 2 2404 7010
412 1 Bevel gears 2 2404 4400
413 1 Piston 2 2404 4520
414 1 Piston pin, assy. 2 2404 4960
415 1 Cover 2 2404 4090
416 1 Crankshaft 2 2404 4550
417 2 Roller 2 2404 4570
418 1 Gear pinion 2 2404 4040
419 1 Bushing 2 2404 8080
420 1 Output shaft 2 2404 8090
421 1 Sealing 2 2404 4190
422 1 Output unit housing 2 2404 8010
423 1 Connecting rod 2 2426 4530
424 1 Shaft seal 9 1905 0540 *
425 1 Slip clutch, assy. 2 2404 4920
426 1 O-ring 9 1901 3500 *
427 2 O-ring 9 1901 3290 *
428 1 O-ring 9 1921 2140 *
429 1 Pressure spring 9 1803 4190
430 1 Feather key 9 1501 1140
431 4 Roller 2 2404 4580
432 1 O-ring 9 1901 5940
*
