Spare Parts List
Description: Part and drawing number:
Output unit, assy. 2 2426 7000
Item Qty. Description Part and Drawing no. Remarks
433 1 Scraper 9 1908 1780
434 1 Pressure spring 9 1807 0210
435 1 Feather key 9 1501 1040
436 1 Needle sleeve 9 1014 0450 *
437 1 Needle sleeve 9 1014 0010 *
438 2 Socket head screw 9 1112 2020
439 1 Grooved ball bearing 9 1004 0010 *
440 1 Snap ring 9 1703 0080
441 1 O-ring 9 1901 3270 *
442 1 Snap ring 9 1703 0130
443 1 Grooved ball bearing 9 1003 0050 *
444 1 Grooved ball bearing 9 1003 0020 *
445 1 Grooved ball bearing 9 1001 0070 *
446 1 Sealing ring 9 1913 0730 *
448 1 Snap ring 9 1702 0050
449 1 Snap ring 9 1702 0040
450 1 O-ring 9 1901 5970 *
451 2 Socket head-screw 9 1110 4030
452 2 Sealing U-shape 9 1908 1930
453 2 Sealing U-shape 9 1908 1950 *
454 1 O-ring 9 1901 2610 *
455 1 Sliding bearing 9 1029 0130 *
456 1 Shaft sealing ring 9 1905 1580 *
457 1 Snap ring 9 1702 0020
458 1 O-ring 9 1901 4070 *
* Wear parts to be stored in case of
continuous use!
