Spitznas 2 2406 0010 - Hydraulic Motor Parts List

Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
7
of
1
4
Spare Part List
Description: Part and drawing number:
Hydraulic Motor 2 2406 1000
Item Qty. Description Part and drawing no. Remarks
100 1 Hydraulic motor 9 5501 0130 with item 104-114
104 1 Shaft sealing ring 9 1925 0450 *
106 1 Axial disc 9 1024 0360 *
107 1 Axial thrust bearing 9 1024 0370 *
108 1 Spacer 9 5501 0040
109 1 Carrier 9 5501 0140
110 1 Drive shaft 9 5501 0150
111 3 O-ring 9 1921 1240 *
112 1 Cover disc 9 5501 0070
113 1 Geroler element 9 5501 0160
114 1 Rotary slide 9 5501 0090
115 1 Bushing 9 1029 0530
151 1 Housing, assy. 2 2406 1910 with item 115
152 1 Motor cover, assy. 2 2407 1930 with item 172
153 1 Centring cover, assy, 2 2406 1940
154 1 Pinnion shaft 2 2406 4170
155 1 Gear rim 2 2406 4020
156 1 Pinion 3 8837 4360
157 2 Planet carrier, assy. 3 8837 4920
158 6 Planet wheel 3 8837 4140
159 6 Needle cage 9 1015 0790
160 2 Grooved ball bearing 9 1001 0050 *
161 1 Washer 2 2406 4150
162 1 Snap ring 9 1702 0030
163 1 Snap ring 9 1703 0040
164 2 Cylinder pin 9 1619 1350
165 3 Socket head screw 9 1110 4010
166 3 Gasket 9 1903 1250 *
167 2 Cylinder pin 9 1619 0450
168 1 Driver shaft 2 2406 1050
169 5 Socket head screw 9 1110 4160
