Hyd ra ulic Hammer Drill
2 2406 0010
Ma s ch in e n f a br ik Gmb H
Translation of the original repair
instruction, compiled: 16.05.17
224060010_Inst_en_Version_06.doc
Page
8
of
1
4
Spare Part List
Description: Part and drawing number:
Hydraulic Motor 2 2406 1000
Item Qty. Description Part and drawing no. Remarks
170 2 O-ring 9 1921 4410 *
171 2 Plug 9 3401 1060 *
172 2 Threaded pin 9 1140 5080
173 2 Socket head screw 9 1110 4030
301 1 Governor sleeve 2 1317 3310
302 1 Glate 5 1220 3050
303 1 Washer 9 3302 0030
304 1 Pressure spring 9 1803 3590
305 1 Locking washer 9 1706 0140
1 Valve innert, assy. 2 1317 3300 item 307-326
307 1 Snap ring 9 1703 0260
308 1 Socket head screw 9 1110 2090
309 1 Washer 9 3302 0150
310 1 Governor piston valve 2 1317 3320
311 1 Spring plate 2 1317 3070
312 1 Slide 2 1317 3110
314 1 Sleeve 2 1317 3090 *
315 1 Guide 2 1317 3100
317 1 Pressure spring 9 1803 1700
318 1 Locking washer 9 1706 0180
319 1 O-ring 9 1901 3290 *
320 1 O-ring 9 1901 9800 *
321 1 O-ring 9 1901 2550 *
322 1 Threaded pin 9 1148 3030
323 1 O-ring 9 1901 6020 *
326 1 O-ring 9 1901 2080 *
*Wear parts to be stored in case of continuous
use
