SPL 2381 - Rear Panel Graphic & Cabling Overview; Voltage Setting and Fuse Ratings

6
MTC 2381
Graphics “DAW“ and “Speakers“ by courtesy of Christian Preissig,
media dell‘ arte - text&ton, E-Mail: media_dell_arte@mac.com
i. e. Metering, Recorder etc.
Alternative
Talkback
Monitoring
Footswitch or Key/Button
Stereo Sources (Audio Player etc.)
Headphone Preamp +
Headphones for Cue-Mix
and Talkback signals
Speaker-Set 1Speaker-Set 2Speaker-Set 3
The following graph shows the correct wiring for connecting
unbalanced signals to the balanced XLR connectors:
1
2
3
1
2
3
1
2
3
Pin Wiring XLR Connectors:
1=GND, 2=hot (+), 3=cold (-)
Pin Wiring 1/4 inch Jacks:
Tip=hot (+), Ring=cold (-), Sleeve=GND
balanced
unbalanced
Musician's Signal
RCA
RCA
Jacks Jacks
