Spokey EVEN - Page 5

| 5EN | instructioni
4. LIST OF PARTS
5. TECHNICAL SPECIFICATIONS
Nr Fittings szt.
1 remote controller 1
2 Silicone oil 1
3 5mm wrench 1
4 6mm wrench 1
5 Multi- wrench 1
6 M6*10 screws 4
7 M6 washers 4
8 Lock screws 2
7. FOLDING
AND TRANSPORT OF THE TREADMILL (D)
6. ASSEMBLY INSTRUCTIONS (B- C) EVEN +
8. COUNTER
ATTENTION! Do not connect the device to the po-
wer source until you nish the assembly
STEP 1 Carry out the machine from the package
by two persons and place it lightly on at oor,
and put other ttings beside the machine.
Lift the handrail up and fasten it to the main
frame with M6*10 screws and at washers. Lock
with 2pcs lock screws.
STEP 2 Adjust the pad holder to the right angle,
then plug on and turn power on to use the ma-
chine.
STEP 3 When not using the handle, unlock and
ACTIVATION
Connect the plug to the socket, the counter
display turns on and the track goes into standby
mode.
SLEEP MODE
After 10 minutes of inactivity, the track goes into
sleep mode and the counter is turned o. Press
any button to resume the track.
BUTTON FUNCTIONS
START/STOP press to start the training or a
chosen programme. 3 seconds after the start,
the running belt will start moving at the lowest
possible speed or at the speed corresponding to
a chosen programme. Press to stop the training.
The treadmill will be slowing down until it stops
completely.
LED display: Speed range 1 KM - 6 KM.
Press “Speed +” key, speed will go up by 0.5 km.
Press “Speed -” key, speed will go down by
0.5km.
DISPLAY INFORMATION
SPEED: current speed.
TIME: the screen displays the value marked with a
glowing diode: time, during the current training
session.
MEASUREMENT RANGE
Speed – adjustable between 0 and 6 km
• Dimensions of the assembled exercise
machine:
147 x 59 x 15cm (EVEN)
147 x 68 x 109cm(EVEN+)
• Running belt: 41 x 115 cm
• Maximum weight of the user - 90 kg
• Voltage: ~ 220-240 V (50/60Hz)
undo the screws, then lower the handrail to the
initial position and lock it to the main frame.
